مكان المنشأ:
الصين/كمبوديا
اسم العلامة التجارية:
Suntek
إصدار الشهادات:
ISO9001, ISO13485, TS16949 and UL E476377
رقم الموديل:
F9632-7582
فيديو
Suntek provide:
-PCB/FPC fabrication
-Components sourcing
-PCB/FPC assembly
-Custom cable/harness assembly
-Box build
Services as below:
-SMT, THT, BGA,0201 Chips assembly
-AOI, X-Ray, ICT, FT, Burn-in
-Conformal coating or gluing
-High-mix, small to medium volume
With certification by ISO9001, ISO13485, TS16949 and UL .
SMT Parameters:
| H 高 | ◆SMT+ICT+THT+FT ◆SMT+ICT+THT+Harness+Assembly+FT |
◆SMT machine(for printing,pick place,reflow soldering) ◆THT machine(for wave soldering) ◆Terminal machine... |
◆AOI ◆X-RAY ◆injection molding machine ◆AI(Automatic Inserting machine)... |
| M 中 |
◆SMT+ICT ◆THT+FT ◆SMT+THT ◆THT+Harness+FT ◆Assembly+FT |
◆ Genera SMD+DIP ◆ DIP parts+ Harness ◆SMD+DIP+Harness without injection molding |
◆≤0201 SMD ◆BGA,LGA,FBGA,LCC+LGA ◆Harness+injection molding ◆Conformal coating |
| S 低 |
◆纯SMT(Only SMT) ◆纯THT(Only THT) ◆纯线束(Only Harness) ◆纯组装(Only Assembly) |
◆代工代料 Material+ Assembly | ◆设计+代工代料 Design+Meterial+Assembly |
| low | higher | highest |
Technology Involved:
| Technology | Circuit | PCB/Flex/Metal PCB/Rigid-Flex | Parameter | Assembly Side | Single/Double |
| Process | SMT | Min Size | 10mm * 10mm | ||
| THT | Max Size | 410mm * 350mm | |||
| Punch | Thickness | 0.38mm ~ 6.00mm | |||
| In-circuit Test Function Test | Min Chip | 0201 chip | |||
| Glue,Burn-in Conformal Coating | Fine-pitch | 0.20mm | |||
| BGA Re-work | BGA ball size | 0.28mm |
Special Technology Involved
◆ IC Programming
◆ BGA rework
◆ Chip on Board/COB
◆ Eutectic soldering
◆ Auto-Gluing
◆ Conformal Coating
Assemly Flow Chart:
